This sensor is designed to measure absolute air-pressure, especially the air box pressure of gasoline or Diesel engines.
An integrated circuit combines a piezo-resistive sensor element and an electronic for signal-amplification and temperature compensation.
The output of the sensor is a 0-5v Analogue signal.
Range 0.2—3.0 Bar Absolute.
For further information and downloads for this product, please follow this link to the Bosch Motorsport Product Page.This sensor is designed to measure absolute air-pressure, especially the air box pressure of gasoline or Diesel engines.
An integrated circuit combines a piezo-resistive sensor element and electronics for signal-amplification and temperature compensation.
The output of the sensor is a 0-5v Analogue Signal.
Range 0.1—1.15 Bar Absolute.
For further information and downloads for this product, please follow this link to the Bosch Motorsport Product Page.This sensor is designed to measure absolute pressure of various kinds of media e.g. Diesel, gasoline, water, engine oil, transmission oil or air. The sensor is available for two different supply voltage ranges.
The sensor uses stainless steel measuring cells with piezo-resistive measuring bridges in thin layer technique, which are hermetically welded together with stainless steel pressure ports. This guarantees a complete media compatibility. The main benefit of this sensor is the high quality of a production part at a low price.
Range 0-10 Bar.
For further information and downloads for this product, please follow this link to the Bosch Motorsport Product Page.The PSS is specially designed to measure absolute pressure in gasoline direct injection applications. This sensor is also compatible with other kind of fluids e.g. Diesel, engine oil, transmission oil or brake fluid.
The sensor uses a thin layer technique to achieve high accuracy pressure measurements. The stainless steel measuring cells with piezoresistive bridges are hermetically welded with stainless steel pressure ports. The internal reference ensures ambient pressure independent measurements. The main benefits of this sensor are its high accuracy, its wide measurement range and its robust and compact design.
Ranges Available– 0-140, 0-260, 0-420 and 0-600 Bar.
For further information and downloads for this product, please follow this link to the Bosch Motorsport Product Page.
